Name: High Speed 9 Colors Offset Digital Printing Machine HTS-220-9C
Availability: InStock

High Speed 9 Colors Offset Digital Printing Machine HTS-220-9C

High Speed 9 Colors Offset Digital Printing Machine HTS-220-9C is designed for efficiency and versatility, equipped with 9 sets of printing modules to achieve vivid and accurate color reproduction. It supports a variety of printing modes, ensuring flexibility for different applications and materials. With high-speed performance and stable output, this machine is an ideal solution for professional, high-quality digital printing needs.

Item No :
HTS-220-9C
Order(MOQ) :
1
Product Origin :
Baiyun District, Guangzhou City, Guangdong Provinc
Weight :
3500kg

Product Details

The High Speed 9 Colors Offset Digital Printing Machine delivers vivid full-color output, supports variable data printing, and covers over 95% of Pantone colors with its multi-spot color mixing technology. Featuring high-speed piezoelectric nozzles (up to 50m/min, 600×1200dpi), it ensures precision and durability while printing directly on paper, PVC, PET, BOPP, and even metallic foils—without pre-coating, reducing processes and costs.

FEATURES

1.It can be equipped with nine printing modules and various printing processes can be realized. Easily achieve full-color printing on both transparent and non-transparent materials, supporting functions such as mostly queuing, plateless printing, starting from one sheet, and variable data.

2. The multi-spot color mixed printing mode makes the printing color gamut more extensive, further expands the printing range, reduces the ink cost, shortens the printing process, and greatly improves the efficiency.

3. It adopts the world's most advanced high-speed and high-precision industrial on-demand piezoelectric nozzles, with a speed of up to 50M/min and an accuracy of 600x1200dpi. It features high quality, high precision and a long service life.

4. The printing is a non-contact inkjet method, and no additional coating is required during the printing process. It has strong adaptability to materials such as paper, PVC, PET, PE, BOPP, gold and silver foil, etc. The surface does not require a pre-coating, reducing the process and lowering costs.

Specification

Printing Technology	Single-Pass UV Inkjet Techonology With Kyocera Printhead	Air Source	0.6~ 0.8 MP
Resolution	600600 & 6001200 DPI	Power Supply	3 Phase + N+ PE/380VAC 50/60 HZ
Printing Speed (m/min)	5-50 m/min *The maximum printing speed may vary by complexity of printing file	of printing file Formats	PDF, TIFF
Material Type	Coated or Uncoated Paper, Transparent or Non-Transparent Materials	Computer Hardware	Mainboard: HTS-Prime Z370-A, Graphics card:GTX1070-O8G
Winder Roll Diameter	Maximum 600 mm	Printing Substrate Thickness	0.045 -0.8mm For Roll to Roll material
Web Width	Minimum: 220 mm Maximum: 330 mm	Image Processor	RIP Bundling: Synchronizes printing and RIP for large data files, saving worktime.
Actual Printing Width	Minimum: 216 mm Maximum: 324 mm	Drying Method	Two-step curing process, each set of printheads undergoes pre-curing followed by overall UV curing. Printhead LED:700W/Lamp. Final Uv Curing:10KW UV
Ink Type	LED Curing Ink	Drying Method
Printing Color Group	4-9 Unit, Colors: CMYK + Optional whiteOrange, Green, Violet, Varnish	Temperature Range	18 ~ 30°C
Machine Dimensions *(LWH)*	About 400020401850 mm Size may vary by customer's required configuration	Equipment Storage Temperature	16 ~ 32°C
Machine Weight	About 3500 KG Weight may vary by customer's required configuration	Ink Storage Temperature	40 ~ 60°C
